Diamond Audio MP654 MP Series 6.5-inch 2-Way Coaxial Horn Speaker

Crank up your ride with Diamond Audio’s MP Series speakers, featuring a punchy 6.5-inch design and crystal-clear horn tweeter. These power-efficient units deliver booming, high-decibel audio that handles the toughest road or water conditions with ease. With a durable cast basket and replaceable diaphragm, you get long-lasting performance that keeps the party going. Transform your motorcycle, boat, or RV into a rolling concert stage with this high-performance audio upgrade.

• Power: 150W RMS/300w MAX
• SPL(dB) MidBass: 92.7
• SPL(dB) Tweeter: 107
• Re(Ω): 3.2
• Qms: 10.73
• Qes: 0.47
• Qts: 0.45
• Fs(Hz): 103.3
• Vas(L): 6.6
• Cms(mm/N): 0.24
• Mms(g): 90.7
• Sd(cm²): 138.9
• BL(T*M): 6.5
• Xmax(mm): 1.0
• Hi-pass Filter: 12dB 2nd Order Crossover

DIMENSIONS

• Diameter: 6.5" (165.5mm)
• Mounting Diameter: 5.73" (145.5mm)
• Mounting Depth: 3.33" (91.6)
• Total Depth: 3.88" (98.6mm)
• Magnet Diameter: 3.94" (100mm)

FEATURES

• NEO Magnet
• Heavy Duty Steel Basket
• Mid Driver: 1.5" Single Layer High Temp 4Ω Voice Coil
• Tweeter: 1.0" 8 Ohm - Single Layer High Temp Voice Coil
• Frequency Response: 110Hz -18Khz
• High Sensitivity 101dB 1W/1M
• 12dB 2nd Order Filter Crossover
