Diamond Audio MP694 MP Series 6x9 Inch 2-Way Coaxial Horn Speakers

Turn your ride into a rolling concert with the Diamond Audio MP Series coaxial speakers. These punchy 6x9 inch drivers feature a high-output horn tweeter that cuts through wind and road noise with ease. Built with a rugged cast basket, they are ready for the sonic adventures waiting on your boat, motorcycle, or off-road rig. Crank up the volume and let the crystal-clear highs and deep, rich bass transform every journey.

• Power: 150W RMS/300W MAX
• SPL(dB) MidBass: 95.6
• SPL(dB) Tweeter: 107
• Re(Ω): 3.2
• Qms: 9.42
• Qes: 0.43
• Qts: 0.42
• Fs(Hz): 82.6
• Vas(L): 18.2
• Cms(mm/N): 0.25
• Mms(g): 15.1
• Sd(cm²): 229.7
• BL (T*M): 7.6
• Xmax(mm): 1.0
• Hi-pass Filter: 12dB 2nd Order Crossover

DIMENSIONS

• Diameter: 9.33"x6.57" (237mm x 167mm)
• Mounting Diameter: 8.86"x5.98" (225mm x 152mm)
• Mounting Depth: 3.99" (101.3mm)
• Total Depth: 4.26" (108.3mm)
• Magnet Diameter: 3.94" (100mm)

FEATURES

• NEO Magnet
• Heavy Duty Steel Basket
• Mid Driver: 1.5" Single Layer High Temp 4Ω Voice Coil
• Tweeter: 1.0" 8 Ohm - Single Layer High Temp Voice Coil
• Frequency Response: 80Hz -18Khz
• High Sensitivity 101dB 1W/1M
• 12dB 2nd Order Filter Crossover
