Features
- High Temperature Voice Coil
- 120 oz. Ceramic Ferrite Magnet ( EWX8D2/8D4 Only )
- 145 oz. Ceramic Ferrite Magnet
- High Grade Low Carbon Steel Top & Bottom Plate
- Design to optimize SPL Performance
- 1.5” High Roll Foam Surround
- Large Gauge Push Button Speaker Terminals
- Available in Dual 2Ω or Dual 4Ω Voice Coil
Specifications
| Structure |
12” (304mm) |
| Max Power |
4000 Watts |
| Nominal Power |
2000 Watts |
| Impedance |
Dual 4Ω Voice Coil |
| PARAMETERS |
| Resonant Frequency (fs) |
34.632Hz |
| D.C. Voice Coil Resistance (Re) |
3.2Ω + 3.2Ω |
| Mechanical Quality Factor (Qms) |
4.912 |
| Electrical Quality Factor (Qes) |
1.088 |
| Total Quality Factor (Qts) |
0.891 |
| Equivalent Air Volume to Cms (Vas) |
26.084L |
| Force Factor (BL) |
20.056 |
| Mass of Diaphragm/Coil (Mms) |
314.235 g |
| Sound Pressure Level (SPL) |
81.9dB |
Description
Feel the beat with the Euphoria EWXC12D4 – the ultimate powerhouse in sound!
Get ready to experience audio like never before with the Euphoria EWXC12D4 12in Subwoofer from the EWX Competition Series. This beast is engineered for those who crave superior sound quality and unmatched performance. With its Dual 4Ω Voice Coil and an astonishing 4000 Watts of max power, it delivers a booming bass that's sure to elevate your music experience. The ceramic ferrite magnet and low carbon steel and bottom plates ensure durability and precision, while the 1.5” wide DFM foam blend and high excursion spider design offer exceptional sound clarity and depth. Encased in a die-cast aluminum vented basket, this subwoofer is built to last and perform at the highest level. Whether you're a car audio enthusiast or a professional competitor, the Euphoria EWXC12D4 is designed to optimize SPL performance and bring every beat to life. Feel the euphoria of extraordinary sound today!
Product Manual
Product Manual PDF
