The
Infinity Primus PR683F is a
high-efficiency 6"x8" two-way coaxial car speaker pair engineered to deliver smooth, full-range audio upgrades for factory sound configurations. This form factor fits neatly into standard 6x8 openings and many 5x7 factory applications.
Technical Specifications
-
Power Handling: 50 Watts RMS (150 Watts Peak per speaker)
-
Impedance: 3-Ohm (True Four Ohm design safely pulls extra power out of standard factory lines)
-
Frequency Response: 65 Hz – 20,000 Hz
-
Sensitivity: 92 dB at 2.83V
-
Woofer Mounting Depth: 2.312" (2-5/16")
Key Features
-
Patented Plus One™ Woofers: Polypropylene cone architecture expands the overall surface area by up to 35%, boosting midbass output and response efficiency.
-
Edge-Driven Silk Dome Tweeters: True 1/2" silk dome tweeters elevate vocal distribution and high-frequency precision without distortion.
-
Rigid Vented Basket Frames: Designed to cool down voice coils by pulling heat away from the motor assembly to handle continuous loads safely.
- Compact Drop-In Shell: Constructed to maximize drop-in factory placement inside tight vehicle spaces without major custom frame modifications.
Audio Performance
-
RMS Power Handling: 50 Watts
-
Peak Power Handling: 150 Watts
-
Frequency Response: 65 Hz – 20,000 Hz
-
Sensitivity: 92 dB at 2.83V
-
Impedance: 3-Ohm True Four Ohm technology
Driver & Material Details
-
Speaker Design: 2-Way Coaxial System
-
Woofer Size: 6" x 8" (Also fits 5" x 7" openings)
-
Woofer Composition: Plus One+ Polypropylene
-
Woofer Surround: Hi-Roll Rubber
-
Tweeter Size: 1/2"
-
Tweeter Design: Edge-driven dome
-
Tweeter Composition: Silk
Physical Dimensions
-
Woofer Top-Mount Depth: 2.312" (2-5/16")
-
Woofer Bottom-Mount Depth: 2.50" (2-1/2")
-
Cutout Dimensions: 7.187" x 5.0" (7-3/16" x 5")
-
Mounting Height: 0.32"
System Features
-
Crossover: Integrated on-speaker network
-
Tweeter Level Control: Fixed (Standard attenuation handled via integrated network)
- Grilles: Not included (Designed for factory location installation behind door panels)
