The JBL Celebrity 150 is an upgraded, high-output single-DIN mechless digital media receiver built for modern car audio configurations. Engineered to replace basic factory stereos, it delivers robust digital media source connectivity and enhanced multi-channel pre-amplifier distribution within a highly compact chassis.
Chassis Form Factor & Interface
-
Standard 1-DIN Profile: Conforms strictly to standard ISO 7736 dashboard layouts measuring 50mm H x 178mm W.
-
Ultra-Shallow Mechless Depth: Omits a physical CD/DVD mechanism, reducing the total active mounting depth to a compact 87mm. This maximizes physical breathing room for heat dissipation and simplifies wiring inside shallow dashboard cavities.
-
Anti-Theft Removable Faceplate: Features a fully mechanically detachable front faceplate panel utilizing multi-pin, gold-plated spring contacts to safely bridge data and system power.
-
High-Luminance LCD Panel: Features a segmented, high-contrast LCD text display with updated interface typography for enhanced off-axis readability during daytime driving.
Core Architecture Upgrades (vs. Celebrity 100)
-
High-Voltage Pre-Amp Stage: Integrates 2 pairs (4 discrete channels) of high-voltage 4-Volt RCA pre-amplifier outputs (Front and Rear/Subwoofer switchable). This high-voltage floor drastically limits induced line noise to deliver clean, unclipped signals to external amplifiers.
-
Dual-Band AM/FM Tuner: Expands radio frequency coverage to include both AM and FM frequencies, utilizing an upgraded non-volatile memory matrix to store up to 30 station presets (18 FM / 12 AM).
Electro-Acoustic Specifications
-
Power Amplification Topology: Monolithic Class-AB Bridge-Tied Load (BTL) multi-channel power integrated circuit.
-
Continuous Power Output (RMS): 20 Watts RMS x 4 channels driven directly into standard 4-Ohm speaker voice coils at ≤1% THD+N.
-
Peak Power Capacity: 50 Watts x 4 channels maximum transient output.
-
System Frequency Response: 20 Hz to 20,000 Hz operational bandwidth.
-
Acoustic Adjustments: Features hardcoded Digital Signal Processing (DSP) presets including pre-configured tonal curves and multi-step loudness compensation.
Media Decoding & Connectivity Infrastructure
-
Wireless Transceiver Core: Built-in Bluetooth RF module operating on the 2.4 GHz band supporting an active operational radius of up to 10 meters (33 feet). Native support maps directly to standard profiles:
-
A2DP 1.2 / AVRCP: High-fidelity wireless audio streaming and metadata synchronization.
-
HFP / HSP: Hands-free telephony linked directly to a high-gain acoustic microphone capsule integrated into the front control face.
-
Local Physical Input Ports:
-
Front USB Port: Type-A high-speed host controller reading flash drives formatted in FAT16/FAT32 for hardware playback of compressed MP3 media containers.
-
SD Card Slot: Dedicated media card bus positioned safely behind the removable faceplate panel.
-
Front AUX Input: High-impedance 3.5mm stereo TRS analog pass-through jack.
- Electrical Safety: Main 16-pin ISO power input block is hard-fused via a rear-mounted 10-Amp automotive blade fuse.
