The tweeter has a PPTA dome diaphragm, and it's fluid-cooled for high power handling. PPTA is a poly material that is among the lightest and most responsive speaker materials developed. PPTA has high inner loss characteristics, which results in effective resonance damping. This material provides performance similar to metal diaphragm materials, but without the harshness often associated with metal diaphragms. The result is detailed, dynamic sound reproduction.
Each Tweeter has a non-removable metal grille attached.
The tweeters may be surface or flush mounted. The tweeters do not swivel when flush or surface mounted.
| PRODUCT PERFORMANCE | |
|---|---|
|
Continuous Power handling (RMS) - Watts
40W
|
Crossover Frequency
NA
|
|
Frequency Response
2500 Hz to 30 kHz
|
Maximum Peak Power Handling - Watts
120W
|
|
Nominal Impedance - Ohm
4-Ohm
|
Sensitivity (1W/1m)
90dB (1w/1m)
|
|
System-Type
Hard Dome - Tweeter
|
|
| FEATURES | |
|---|---|
|
Cut Out dimensions
----
|
Mounting Depth
3/4" - Tweeter
|
|
Outer Diameter
2-1/4"
|
Protrusion
3/8"
|
|
Speaker Grill
NA
|
Tweeter
22mm
|
|
Tweeter Mounting Hole Diameter
2"
|
|
| MATERIALS | |
|---|---|
|
Damper
NA
|
Diaphragm Material
Polyimide - Tweeter
|
|
Drive Cone Material
NA
|
Shorting Ring Material
NA
|
|
Surround Material
NA
|
Surround Type
NA
|
|
Voice Coil Material
NA
|
Voice Coil wire
NA
|
