The Z-Series is based on highly advanced technology developed by Pioneer, utilizing carefully selected materials and parts, and benefiting from our decades of automotive loudspeaker design theory and testing expertise. Following Pioneer’s OPEN & SMOOTH™ sound concept, the Z-Series automotive loudspeakers feature smooth off-axis frequency response, superior directivity, and an extended frequency range, engineered specifically to produce dynamic, accurate sound quality for your car. The result is a purity of sound that achieves unprecedented audio artistry.
The quality of music recordings available to listeners has evolved. Hi-Res Audio recordings contain significantly more data compared to a standard CD recording and require a loudspeaker that is capable of smoothly reproducing frequencies of 40kHz or higher. The Z speakers are designed to deliver sound that’s clearer, sharper and more complex - reproducing music that is closer to the original performance.
All Z-Series speakers feature the same tweeter without any alterations. From the largest component speaker set to the smallest 2-way coaxial speaker, you will get the same tweeter to ensure perfect tonal balance throughout the car, regardless of the size of speakers required for the front and rear.
Pioneer’s OPEN & SMOOTH sound concept ensures a seamless and smooth transition between the midrange and tweeter drivers, delivering a uniform off-axis frequency response. This design is optimized for automotive applications where one or more speakers are often aimed away from the listeners’ ears.
Twaron® is a synthetic aramid fiber that is very strong, heat-resistant, and rigid when woven into a cloth material. The woofer cones created with Twaron® are rigid and low mass with excellent damping characteristics. Strength and rigidity are important to maintain cone shape during challenging bass notes, while damping is critical for improving responsiveness and signal accuracy.
The Z tweeter’s aluminum alloy diaphragm allows the tweeter to remain pistonic and linear at ultrasonic frequencies. The unique diaphragm shape, developed using HSDOM (Harmonized Synthetic Diaphragm Optimum Method) computer analysis, accurately controls differential vibration produced by the diaphragm and improves high frequency dispersion. Pioneer’s Vertex Drive System improves the mechanical coupling of the voice coil and the tweeter diaphragm, reducing distortion and coloration caused by low damping and increasing power handling.
Avoid messy installations and keep your speaker wiring as clean as possible. These speakers use an in-line crossover design and/or an integrated crossover already installed on the speaker basket. This eliminates the need for a bulky external box typically found with passive crossovers, saving you from having to find extra space for it. Additionally, it removes the need for extra wires going in and out of your door to accommodate a woofer in the door with a matching tweeter on your dash.
Pioneer's Car Sound Fit app is a car sound simulator that lets you experience what your car could sound like using your own smartphone. You'll be able to hear the difference between stock speakers and Pioneer's various audio options, and see how the quality of Pioneer speakers can enhance your in-car experience. For a virtual listening demo of these and many other Pioneer car speakers, download the free Pioneer CarSoundFit app.
| PRODUCT PERFORMANCE | |
|---|---|
|
Continuous Power handling (RMS) - Watts
110
|
Crossover Frequency
4000Hz (Acoustic),2200 Hz (Electric)
|
|
Frequency Response
32 Hz to 96 kHz
|
Hi-Res Certified
Yes
|
|
Maximum Peak Power Handling - Watts
330
|
Nominal Impedance - Ohm
4-Ohm
|
|
Sensitivity (1W/1m)
85 dB (+- 1.5dB)
|
System-Type
Coaxial 2-way,Balanced Dome - Midrange
|
| FEATURES | |
|---|---|
|
Cut Out dimensions
5-5/8"
|
Mounting Depth
2-1/2" - Midrange
|
|
Speaker Grill
NA
|
Tweeter
29mm
|
|
Tweeter - Swivel Type
Yes
|
|
| MATERIALS | |
|---|---|
|
Basket Material
Stamped Steel
|
Cone Material
Twaron Aramid Fiber
|
|
Damper
Aramid Fiber
|
Diaphragm Material
Aluminum Alloy - Tweeter
|
|
Magnet Material
Ferrite - Speaker,Neodymium - Tweeter
|
Magnet Weight
11.3 oz - Speaker,0.2 oz - Tweeter
|
|
Shorting Ring Material
Copper
|
Surround Material
Butyl Rubber
|
|
Surround Type
Rolled
|
Voice Coil Material
Glass Imide
|
|
Voice Coil wire
Copper
|
Wire Terminals
Lug Type
|
