Rockford Fosgate PMX-HD9813

Rockford Fosgate PMX-HD9813

In stock

Digital Media Receiver for Select 1998-2013 Harley-Davidson Models

  • price-tag logoNew Launch
$659.99
$659.99
Save: $-659.99 (% Off)*
Sale Sold out
Shipping calculated at checkout.
  • cargo-truck logoFree shipping Over $99
Sold in last hours
  • Amazon
  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Venmo
  • Visa
  • free logo
    Fast, FREE Delivery

    Free, Fast, Doorstep Delight!

  • return logo
    Delivery & Returns

    Effortless Delivery, Easy Returns

View full details
  • Overview
  • Details
  • Accessories

Direct replacement digital media receiver for select 1998 - 2013 Harley-Davidson® motorcycles.  Features 3-inch full color, ultra-bright display with day/night modes and oversized buttons for easy control.  Engineered for the ultimate in performance and sound quality featuring 4-Volt pre-amp outputs that don't clip! Plug and play installation with OEM electrical system requires no additional wiring or cutting of existing factory harnesses or components.  Retains factory thumb controls.

Plug and play installation requires factory wiring harness and connectors in order to retain functionality.  Systems requiring rear speaker-line outputs will require additional harness (sold separately.) PMX source unit not compatible with factory amplified systems, CB, Intercom, rear volume controls, rear speakers on 1998-2005 Ultra’s, and factory equipped satellite radio systems. Estimated Installation Time: 1 HOUR.

Features:

  • 1998-2013 Harley-Davidson® direct replacement digital media receiver
  • A2DP and AVRCP Bluetooth® Wireless Streaming
  • USB Input with 1.5A USB Charging
  • Pandora® Internet Radio Control
  • 3" Full Color TFT Display with Day/Night Mode
  • SiriusXM-Ready® satellite radio (requires SXV300 tuner)
  • Digital AM/FM/WB tuner with presets
  • Selectable HP/LP/AP Crossover with Selectable 12/24 dB/Octave Slope
  • AUX Input
  • Software updatable via USB
  • Retains factory thumb control functionality with no additional parts
  • Voltage gauge with Low voltage Warning
  • 7-Band Graphic EQ + PEQ
  • Plug and Play Installation with OEM electrical connectors
  • Independent Subwoofer Level Control
  • Compatible with PMX-BTUR Remote control
  • Multi-region radio frequencies
  • 2-Year Warranty
  • *Antenna not included

Specifications:

Crossover Sub-Out variable from 60 Hz - 120 Hz
Channel Separation RCA: > 50 dB, High-Level: > 50 dB
Signal-to-Noise Ratio RCA 2V: > 85 dB, High Level (CEA-2006): > 75 dB
Max Wrms > 80 dB
Output Power (CEA-2006 Rating) 25W x 4 @ 4Ω RMS, 50W x 4 @ 2Ω MAX
THD+N ≤ 1.0%
RCA Output Voltage Front: 4 V Max, Rear: 4 V Max, Sub: 4 V Max
Frequency Response RCA: 20Hz - 20 kHz, High-Level: 20Hz - 20 kHz
Idle Current < 2 Amps
Operating Voltage 9.5 - 16 VDC
THD+N (4-Ohms) < 1.0 %
Output Impedance < 500 Ohms
AM Tuner Range: 530 - 1710 kHz, Sensitivity: 40 dB
AM Frequency Response 45 to 2.4 kHz
USB Version 2.0
Bluetooth® 3.0+EDR, A2DP 1.3
FM Tuner Range: 87.9 - 107.9 MHz, Sensitivity: 8 dB
FM Frequency Response 20 - 15 kHz
Supported Media Formats MP3, WMA
Clock Yes
USB Output Current 1.5A
USB Capacity 32 GB max, 255 Folders max, 999 Songs max
USB Format (Win) FAT32
USB Format (Mac) MS-DOS (FAT)
Display Size 3" Color TFT, Resolution: 960 x 240
Display Brightness 380 nits
Display Contrast 400
Display Pixels 320 x 240
View Angle 120°
Shipping Weight 4.75 lbs (2.15 kg)
Made for iPhone Models XS Max, XR, 8 Plus, 7 Plus, SE, 6s, 6, 5c, XS, X, 8, 7, 6s Plus, 6 Plus, 5s, 5
Made for iPod Models iPod touch (5th/6th gen)
Dimensions (Faceplate) 2.7" x 8.4" x 0.7" (68.4 mm x 213 mm x 17.1 mm)
Dimensions (Chassis) 2.5" x 8.2" x 7.5" (63.5 mm x 209.3 mm x 191 mm)
