Primed for Performance, the R2-750X5 is a 750 watt rated, full-range class-D amplifier capable of operating at 4Ω or 2Ω stereo with a mono subwoofer channel that can be run at 4Ω or 2Ω. The front/rear stereo channels can also be run at a 4Ω bridged/mono load. This amplifier is extremely efficient because of its Class-D technology which reduces demand on the vehicles electrical system. The amp also features C.L.E.A.N. circuitry to help you adjust your gain settings, a P.O.W.E.R. supply that generates more dynamic power as voltage increases, and an integrated Punch EQ that corrects for acoustic deficiencies while delivering up to 3X the bass.
The R2 models were developed for car audio fanatics that want a reliable amplifier – with all the power and performance you’ve come to expect from Rockford Fosgate – at an economical price. Rockford Fosgate amplifiers are renowned world-wide for being “under rated,” easily surpassing all specifications, and most importantly, generating more power over their ratings. These 3rd generation of Prime Series amplifiers are refined with the latest Rockford Fosgate technology for easy setup and configuration, making them perfect for use with factory audio or custom aftermarket systems.
| Feature | Details |
|---|---|
| CTA-2006 Compliant | Yes |
| Number of Channels | 5 |
| Total Power (Sum of Rated Power) | 750 Watts |
| Rated Power (RMS Continuous Power) | 50 Watts x 4 + 200 Watts x 1 @ 4Ω 100 Watts x 4 + 350 Watts x 1 @ 2Ω 200 Watts x 2 + N/A @ 4Ω Bridged/Mono |
| Dynamic Power (PVC/PowerCube®) | 70 Watts x 4 + 241 Watts x 1 @ 4Ω 114 Watts x 4 + 426 Watts x 1 @ 2Ω 234 Watts x 2 + N/A @ 4Ω Bridged/Mono |
| Bridgeable | Yes |
| Frequency Response | 20 Hz - 20 kHz |
| Input Sensitivity | Low-Level: 150 mV - 4 V High-Level: 450 mV - 12 V |
| Circuit Topology Class | Class-D |
| Efficiency (average) | — |
| Total Harmonic Distortion (THD+Noise) | Front/Rear 4Ω: <1.0% Front/Rear 2Ω: <1.0% Sub 4Ω: <1.0% Sub 2Ω: <1.0% |
| Signal Input | Front Low-Level: 2 RCA Front High-Level: 4-Pin Molex Rear Low-Level: 2 RCA Rear High-Level: 4-Pin Molex Sub Low-Level: 2 RCA Sub High-Level: 4-Pin Molex Input Switch: 2/4/5 Input (works for RCA/Hi-Level inputs) |
| Signal Output | N/A |
| Tone Controls | 0 to +18 dB @ 45 Hz |
| Crossover Controls | Front High-Pass: 50 Hz - 250 Hz @ 12dB/Octave Butterworth Front Low-Pass: 50 Hz - 250 Hz @ 12dB/Octave Butterworth Rear High-Pass: 50 Hz - 250 Hz @ 12dB/Octave Butterworth Rear Low-Pass: 50 Hz - 250 Hz @ 12dB/Octave Butterworth Sub Low-Pass: 50 Hz - 250 Hz @ 12dB/Octave Butterworth Sub Infrasonic: 15 Hz - 40 Hz @ 12dB/Octave Butterworth |
| Remote Controls | Yes |
| Visual Indicators | POWER (Blue) / PROTECT (Red) C.L.E.A.N. IN (Red) C.L.E.A.N. OUT Front (Blue/Red) C.L.E.A.N. OUT Rear (Blue/Red) C.L.E.A.N. OUT Sub (Blue/Red) |
| Power Wire Gauge | 4 AWG |
| Power Input Connector | Compression Terminal Block |
| Speaker Wire Gauge | 8 AWG |
| Speaker Output Connector | Compression Terminal Block |
| Cooling | Convection |
| Heatsink | Yes |
| Operating Voltage | 9 - 16 VDC |
| Recommended Fuse (Not Included) | 120 A |
| Average Current Draw (13.8V Music) | — |
| Max. Current Draw (13.8V Sinewave) | 71 A |
| Suggested Alternator | — |
| Included In The Box | Yes |
| Dimensions (H x W x D) | 1.9" x 6.8" x 11.2" (4.9 cm x 17.3 cm x 28.5 cm) |
| Shipping Weight | — |
