Unleash earth-shattering bass from unexpectedly compact enclosures with this powerhouse subwoofer driver. It boasts an incredibly long stroke motor and a bifilar copper voice coil, delivering jaw-dropping linear travel for deep, resonant lows. Featuring a rigid carbon fiber cone and a robust cast aluminum frame, this driver ensures distortion-free audio even at extreme volumes. Get ready to experience your music's lowest frequencies with unparalleled clarity and impact.
| Driver Size | 15 inch |
| One-Way Linear Travel | 1.57 inches (40 mm) |
| Total Linear Travel | 3.15 inches (80 mm) |
| Total Peak Excursion | 4.02 inches (102 mm) |
| Voice Coil | Bifilar Copper with 3 Shorting Rings |
| Spider Material | 10-inch Triple-Layer Nomex |
| Cone Material | Carbon Fiber Sandwich |
| Frame Type | High-Clearance Cast Aluminum |
| Motor Structure | 9.84 inch (250 mm) Triple Stacked |
| Recommended Enclosure Displacement | 0.45 cubic feet |
| Weight | 90 lbs |
| Dimensions (OD) | 15.375 inches |
| Dimensions (Cutout) | 14.125 inches |
| Mounting Depth | 11.875 inches |
| RMS | 2000 watts |
| Re | 4.0 Ohms |
| Fs | 20.9 Hz |
| Qes | 0.38 – |
| Qms | 4.42 – |
| Qts | 0.35 – |
| Le | 3.1 mH |
| Sd | 112.85 square inches |
| Vas | 73.42 Liters |
| BL | 28.65 Tesla Meters |
| Mms | 593.9 grams |
| Cms | 97.6 µM/N |
| Xmax | 40 mm one-way 70% BL |
| SPL | 87.5 dB |
| Cone Material | Carbon Fiber – |
| Voice Coil Material | Copper – |
| Sealed Enclosure Volume | 1.0 cubic feet |
| Minimum Sealed Enclosure Volume | 0.88 cubic feet |
| Maximum Sealed Enclosure Volume | 1.5 cubic feet |
| Ported Enclosure Volume | 1.6 cubic feet |
| Minimum Ported Enclosure Volume | 1.2 cubic feet |
| Maximum Ported Enclosure Volume | 2.0 cubic feet |
| Ported Enclosure Tuning | 23 Hz |
| Port Surface Area | 40 square inches |
| Voice Coil Diameter | 3 inches |
| Terminal Type | Large 4 AWG – |
| Motor Diameter (without boot) | 10.0 inches |
| Motor Diameter (with boot) | 10.25 inches |
